L400C

Digital control indicator convert millivolt signals into clean, reliable outputs ready for DAQ, PLC, and control system integration.

They are trusted by engineers worldwide to deliver best-in-class performance in a wide range of applications including Hydraulic/pneumatic systems, medical, automation and robotics,with the versatility, accuracy, and service support that make a trusted partner for mission-critical systems.

L100B's communication mode includes RS232 and RS485;The analog output includes A1(0-10V), A2(0-20V),A3(0-5V),A4(4-20mA), A5（±5V),A6(±10V)

Besides,it has 1-channel switching input and 3-channel switching output can be choosed.And the indicator suopports TEDS（Transducer electronic date sheet ） function

Download Specification 3D Model Download Online Consultation

Technical features

1. Strong signal compatibility and high adaptability

2. Double optimization of measurement accuracy and stability

3. Improved convenience of operation and maintenance

Specifications

Rated Power Supply	24VDC, 0.25A	Power Supply Range	(18-30) VDC (Over-Voltage Alarm)
Environment Temperature	(- 10-60)℃	Storage Temperature	(- 20- 70)℃
Humidity Range	＜85% RH No Dew Condensation	Pulse Group Immunity	EFT-Level III (2KV Test)
Surge Immunity	Level 4: 4.0KV	Sensor Bridge Voltage	5V ± 1% (Fixed Bridge Voltage)
Sensitivity Range	± 2.4mV/V (Signal Input Range)	Signal Sampling Accuracy	24bit∑-△ADC Sampling
Signal Sampling Rate	10 - 1.2K	Switching Input	1-Channel (Configurable Function)
Switching Output	3-Channel (Configurable Function)	Communication Protocol	ModbusRTU(Read/Write/Read-Only), Active Upload
Transmitting Signal	4-20mA/0-20mA/0-5V/0-10V/±5V/±10V	Transmitter Accuracy	16bit

Product Dimension

Relevant Products

Applications

1.Pressure and flow control:

Hydraulic/pneumatic systems: Equipped with pressure sensors to control the oil pressure of machine tool hydraulic stations (e.g., 3-5MPa) to prevent overloads.

2.Electric equipment monitoring:

Machine tool equipment: monitor cutting force through pressure sensors and control instruments to prevent overload;

Automated production lines: Cooperate with displacement sensors to control the positioning accuracy of robotic arms (e.g., ±0.01mm), ensuring precise execution of processes such as assembly and welding.

label:

Force sensors Multi-Axis Sensors Load cell
