Signal amplification and gain adjustment;
Signal standardization conversion;
Multi-parameter adaptation;
Strong anti-interference ability
Signal amplification and gain adjustment;
Signal standardization conversion;
Multi-parameter adaptation;
Strong anti-interference ability
Supporting solution: torque sensor + torque transmitter
Application scenarios: motor output torque test, bolt tightening machine torque control. The weak signal output by the sensor is amplified and converted, and is used to monitor the equipment running load to avoid overload damage.
| Rated Power Supply | 24VDC, 0.15A | Power Supply Range | (18-30) VDC (Over-Voltage Alarm) |
| Environment Temperature | (- 10-60)℃ | Storage Temperature | (- 20- 70)℃ |
| Humidity Range | ＜85% RH Non-condensation | Pulse Group Immunity | EFT-Level III (2KV Test) |
| Surge Immunity | Level 3: 2.0KV | Sensor Bridge Voltage | 5V ± 1% (Fixed Bridge Voltage) |
| Sensitivity Range | ± 2.4mV/V (Signal Input Range) | Signal Sampling Accuracy | 24bit∑-△ADC Sampling |
| Signal Sampling Rate | 10 - 1.2K | Switching Input | 1-Channel (Configurable Function) |
| Switching Output | 2-Channel (Configurable Function) | Communication Channel | RS485 |
| Communication Protocol | ModbusRTU(Read/Write/Read-Only), Active Upload | Transmitter Accuracy | 16bit |
| Transmitting Signal | 0-20mA/4-20mA/0-5V/0-10V/±5V/±10V |
Pressure monitoring:
Supporting solution: pressure sensor + pressure transmitter
Application scenarios: chemical pipeline pressure monitoring, hydraulic system pressure detection, boiler steam pressure control. For example, in a hydraulic press, the pressure sensor outputs a mV-level signal, which is amplified by the amplifier and converted into a 4-20mA signal by the transmitter, and transmitted to the PLC to control the hydraulic valve opening.
Mechanical engineering and force monitoring
Force and weight measurement:
Supporting solution: strain gauge force sensor/weighing sensor + strain amplifier + transmitter
Application scenarios: crane overload protection (axle pin sensor + transmitter, monitoring the weight of the hoisting load), material tensile testing machine (tension sensor + amplifier, measuring the ultimate strength of the material), truck scale (weighing sensor + transmitter, achieving accurate weighing).
